160x24mm WPC Great Wall wall panel
160x24mm WPC Great Wall wall panel
This 160×24mm co-extruded WPC fluted panel adopts tongue and groove interlocking design. Made of wood plastic composite with an extra co-extruded cap layer, it features outstanding UV resistance, waterproof and anti-termite performance. Fit for both exterior facades, fences, storefronts and indoor feature walls. Easy installation, low maintenance, custom colors and lengths supported.
160×24mm Co-extruded WPC Great Wall Fluted Panel
Our 160×24mm WPC Great Wall fluted panel is a hot-selling co-extruded cladding profile widely used for interior and exterior decoration projects. It is extruded from a scientific blend of natural wood fiber and high-density polyethylene (HDPE), with an integrated compact co-extruded cap layer on the surface. This special outer layer greatly improves the panel’s UV stability and anti-fading performance, which solves the common aging and discoloration problems of ordinary single-layer WPC materials under long-time sunlight exposure. The classic concave-convex Great Wall profile delivers a clean, modern 3D slat visual effect, bringing layered texture and minimalist aesthetic sense to any building space.
Specification
Size: 160mm width × 24mm thickness
Standard length: 2.75m / 2.9m / 3.0m; customizable length range from 2m to 5.8m
Surface option: deep embossed wood grain / solid color
Structure: hollow extrusion profile, lightweight with good rigidity
Connection method: tongue & groove click interlocking system
Core Advantages
Superior weather resistance with co-extruded protective skin. The dense cap layer shields the substrate from ultraviolet radiation, rainwater and temperature change. It keeps stable color and surface condition for many years under direct outdoor sunlight.
Fully waterproof, mildew-proof, rot-proof and termite-proof. Unlike natural solid wood, this WPC panel will not absorb moisture, swell or decay in humid environments. It is perfectly suitable for coastal, rainy and high-humidity regions.
Pre-finished surface, no painting or secondary treatment required on site. It saves labor cost and construction time, and avoids volatile harmful substances brought by paint. The wood grain texture is realistic and comfortable to touch.
Hidden fixing installation. Thanks to the tongue and groove click design, screws can be fixed inside the groove and concealed after assembly. The finished wall surface is tidy without exposed fasteners.
Low maintenance cost. It does not need regular oiling, waxing or anti-insect treatment. Daily cleaning only needs soft brush and clean water to wash away dust in grooves.
Good dimensional stability. The formula and extrusion process effectively reduce shrinkage, warping and cracking caused by temperature difference.
Eco-friendly and recyclable material. It uses recycled HDPE and plant fiber, contains low formaldehyde, meets international environmental standards.
Complete matching accessory system. We supply supporting trims including inner corner, outer corner, H connector, end cap and starting profile. All accessories can match the panel color consistently for perfect edge finishing.
Application Scenarios
Exterior applications: villa facade decoration, store front cladding, garden fence, balcony wall, terrace, pavilion, outdoor lounge backdrop.
Interior applications: TV background wall, sofa feature wall, entrance wall, partition screen, wainscot, hotel lobby, restaurant, office and showroom decoration.
Available Certificates
We can provide relative test reports according to client requirements, including EN 13501-1 fire classification test, REACH compliance report, SGS formaldehyde emission test and UV aging resistance test report. All documents support project bidding and customs inspection.
Important Notes
Co-extruded type is strongly recommended for permanent outdoor places with direct sunlight. Non-co-extruded WPC version is only suggested for indoor or fully shaded areas without UV exposure. Dust may accumulate inside the concave grooves after long use, regular cleaning is suggested to keep good appearance. We support customized color and length for bulk orders. MOQ for custom options is negotiable.
